Log: Displays the Messages - Log pane with a record of Data Modeler actions during the current invocation.Įxternal Log: Displays a separate window with a record of all invocations of Data Modeler for the current full release number.Įxternal Log: Displays a record of Data Modeler actions in an external viewer instead of in a pane within the Data Modeler window.įiles: Displays the Files pane for navigating the local file system. The Navigator appears by default in the right side of the window. Navigator: Displays a graphical thumbnail representation of the view that is currently selected. Show Status Bar: Toggles the displaying of the status bar at the bottom of the Data Modeler window.īrowser: Displays the object browser, which shows data modeling objects in a hierarchical tree format. Recent Designs: Lets you open a Data Modeler design that you recently worked on.Įxit: Closes any open designs and exits Data Modeler.Ĭontains options that affect what is displayed in the Data Modeler interface.
#Oracle sql developer data modeler download pdf#
Print Diagram: Saves the currently selected diagram to an image file of the type associated with the file extension that you specify (.png or.jpg), to a PDF file, to a scalable vector graphics (.svg) file, or to an HTML/SVG (.html) file. Print: Prints the currently selected diagram. Page Setup: Displays a dialog box where you can specify the following for any diagram print operations: media Size (Letter, Legal, or other predefined size) and Source (Automatically Select or a specified paper source), Orientation (Portrait, Landscape, Reverse Portrait, Reverse Landscape), and Margins (left, right, top, bottom). Reports: Lets you generate Data Modeler Reports. For more information, see Saving, Opening, Exporting, and Importing Designs. For more information, see Saving, Opening, Exporting, and Importing Designs.Įxport: Lets you export models to files that can be imported into a variety of data modeling tools. Import: Lets you import models from a variety of sources. For more information, see Saving, Opening, Exporting, and Importing Designs.Ĭlose: Closes the current design without exiting Data Modeler.Ĭlose All: Closes all open designs without exiting Data Modeler. Open: Opens a Data Modeler design that had been saved or exported.
